Medium to large FOV binocular fringe grating 3D camera

The product has a medium to large field of view and depth of field, making it suitable for typical stacking and medium to large workpiece positioning scenarios. The resulting imaging point cloud is both detailed and fast.

AT-S1000-01C-H              AT-S1000-01C-S2              AT-S1000-02C-E

AT-S1000-01C-H-L

Small to medium FOV binocular fringe grating 3D camera

The product has a small to medium field of view and depth of field. Its compact size makes it suitable for mounting on the end-axis of robotic arm EYE-IN-HAND. This allows for scanning of the target workpiece at a close distance in a compact workstation, enabling high-precision positioning and guidance. It is an excellent choice for collaborative and composite robots.

AT-S1000-06C-S              AT-S1000-06C-S2 V2              AT-S1000-06C-S3

Small FOV binocular fringe grating 3D camera

The product provides exceptional positioning accuracy. By identifying the holes, pins, and other features of the target workpiece in close proximity, they can provide precise assembly guidance, positional degree detection, and other process realizations with low tolerance.

AT-S1000-07C-S              AT-S1000-07C-S3

Surface structured light imaging

The imaging speed is limited to 0.6s or less, making it suitable for high-speed production line operations. The point cloud is fine and the blue light imaging technology adapts to environmental lighting and reflective workpiece characteristics.

Binocular Structure

By using a market-proven, mature binocular structure design with an optimal baseline ratio, we can effectively reduce the temperature drift coefficient of optical products. Reducing the risk of lens distortion through software algorithms ensures accurate and stable continuous operation.

Wide FOV Coverage

A range of subtypes are available to choose from, covering a wide range of effective FOV, including super-large, large, small and medium-sized options, to meet the needs of acquiring depth of field data at far, medium and near distances.

Hardware Selection

The product shell is made through CNC one-piece molding, providing excellent anti-vibration performance. The surface is treated for anti-corrosion, wear-resistance, and insulation. It is equipped with top-brand optical components to ensuring long-term stable operation.

Rigorous Quality Control

The products are of industrial-grade quality and have undergone over 30 performance tests before leaving the factory, with a cumulative testing time of more than 10,000 hours.

Plug-and-play

Flexible installation methods are available through our self-developed vision application algorithm platform, ALSON VizMaster. This allows for easy deployment in a variety of production sites.
