B-Series



3D laser profiler

Suitable for high speed positioning, measurement and inspection of dynamic workpieces.

AT-S1000-04B-S600         AT-S1000-04B-S1500





B-Series Advantages



Laser Imaging

Excellent environmental adaptability, easily handling high-brightness ambient lighting and high-dust environments, with strong recognition capability for highly reflective workpieces.



Dynamic Recognition

Compatible with belt and roller conveyors, guiding robots to achieve dynamic positioning, measurement, and inspection of workpieces without stopping.


Wide FOV Coverage

A range of subtypes are available to choose from, covering a wide range of effective fov, including super-large, large, small and medium-sized options, to meet the needs of acquiring depth of field data at far, medium and near distances.



Hardware Selection

The product shell is made through CNC one-piece molding, providing excellent anti-vibration performance. The surface is treated for anti-corrosion, wear-resistance, and insulation. It is equipped with top-brand optical components to ensuring long-term stable operation.


Rigorous Quality Control

The products are of industrial-grade quality and have undergone over 30 performance tests before leaving the factory, with a cumulative testing time of more than 10,000 hours.



Plug-and-play

Flexible installation methods are available through our self-developed vision application algorithm platform, ALSON VizMaster. This allows for easy deployment in a variety of production sites.









AT-S1000-04B-S600  Specifications



Dimensions(L×W×H,mm) 247.5×100×54.5
Weight(kg) 1.2
Laser class Class 2M
Connector(IPC) GigE
IO Port

12-pin M12 connector provides power and IO:

2 encoder interfaces, 1 isolated input, 1 isolated output, 1 RS232 serial port
FOV(mm) 210@275~580@910
Clearance distance(mm) 275
Measuring range(MR)(mm) 275~910
FPS(Hz) 300~4000
Contour points 2048
Resolution X(mm) 0.10~0.35
Repeatability Z(μm) 3.5
Linearity Z(+/-% of MR) 0.01%
Output result 2D image/contour/point cloud
Operation temperature(℃) 0~50
Storage temperature(℃) -20~70
Operation humidity 20%~80%RH(no condensation)
IP rating IP67
Illuminance(Lux) 100000
Power voltage DC24V 1A
Power consumption(typical, W) 10
Power consumption(max, W) 12
Cooling method Passive
Certification CE、FCC、VCCI







Communications Support



The ALSONTECH 3D vision system supports popular robot and PLC brands available in the market.
It can also facilitate communication through various methods such as TCP, UDP, MODBUSTCP, PROFINET, MOTOPLUS, and more.
